OVERVIEW

SPECS

FEATURES

MOTORS & PARTS

OFF ROAD

1:10 2WD Buggy 17.5T/13.5T

1:10 2WD Truck 17.5T/13.5T

1:10 2WD Short Course 17.5T

1:10 4WD Buggy Spec







RS PRO Black Edition

ON ROAD

1:12 2WD Pan Car 17.5T/13.5T

1:10 2WD Pan Car 21.5T/17.5T

1:10 World GT

1:10 2WD Formula 1 25.5T/21.5T

1:10 4WD TC 25.5T/21.5T/17.5T
  1S LiPo Classes



RS PRO Black Edition

OVAL

1:10 2WD 17.5T/13.5T

1:10 SK Car

1:10 Stock Car
  1S LiPo Classes







RS PRO Black Edition

Input Voltage: 1S, 2S - All Motors

Weight: 147g / 5.18oz

Shaft Dimensions: 3.2mm (1/8") x 15.3mm

Motor Diameter: 35.85mm / 1.40"

Motor Length: 50mm / 1.968"

Bearing Dimensions: Front: 4x13x5mm / Rear: 1/8x3/8x5/32"

Rotor Size:  12.5mm High Strength YELLOW

Rebuildable: Yes





Tekin ULR Ultra Low Resistance Design
0-60* Adjustable Timing
CNC Machined 6061-T6 Billet Aluminum Heat Sink Can
New Low Resistance, High Power Solder Tabs

High Strength Neodymium Sintered Magnet
ABEC5 High RPM precision bearings

Precision Engineered for Maximum Energy Conversion
Lightweight Chassis Design

High Purity Copper Windings Maximize Conductivity

Sensor Wire Harness for all Sensored and Sensorless systems

Anodized End-bell plates maximize corrosion and wear resistance

Rebuild-able Design

Solder-less Sensor PCB replacement



















MOTOR ONLY

TT2696 - SPEC-R 21.5T

TT2697 - SPEC-R 17.5T

TT2698 - SPEC-R 13.5T

TT2700 - SPEC-R 6.5T

Tuning Rotors


TT2719 12.3mm Spec Rotor - GREY
TT2721
12.5mm Spec Rotor - BLUE

TT2722 12.5mm Spec Rotor Strong - YELLOW

TT2723 13mm Modified Rotor - GREEN

TT2724 13mm HT* Modified Rotor - RED



Bearings



TT2727 - Redline GEN3 Bearing Set - Front: 4x13x5mm / Rear: 1/8x3/8x5/32"



Motor Parts



TT2725 - Redline GEN3 Rebuild Kit: End Caps / Bearings / Solder Tabs / Isolator / Hardware

TT2726 - Redline GEN3 End Caps / Hardware

TT2728 - Redline GEN3 Sensor PCB

TT2729 - Redline GEN3 Solder Tabs / Isolator



* HT = High Torque Option Rotor



Rotors can be easily identified while installed by the color displayed on the end of the shaft at the rear carrier bearing.
