1:8 4WD Buggy





RX8 GEN3 ESC

ON ROAD

1:8 4WD GT

1:8 4WD GP



RX8 GEN3 ESC

Input Voltage: 2S - 2700kV

                        3S - 2700kV / 1950kV

                        4S - 1950kV

                        5S - 1600kV

                        6S - 1350kV

Weight: 274g / 9.66oz

Shaft Dimensions: 5mm(.125") x 19mm

Motor Diameter: 36mm / 1.41"

Motor Length: 67mm / 2.63"

Bearing Dimensions: Front: 5 x 14 x 5mm / Rear: 5 x 11 x 5mm

Rotor Size: 18.5mm *all

Rebuildable: Yes









CNC Machined 6061 Billet Aluminum Heatsink Can

Precision Engineered for Maximum Energy Conversion

Sensored and Sensorless Operation

Dual-Plug Sensor Wire Harness

4-Pole Neodymium Sintered Magnet

Rebuildable Design

Solder Tabs

High RPM ABEC5 Oversized Bearings

Lightweight Indoor-specific Design

Designed to be paired with the RX8 GEN2 ESC

ROAR Approved



















MOTOR ONLY



TT2385 - T8i 2700kV

TT2386 - T8i 1950kV

TT2387 - T8i 1600kV

TT2388 - T8i 1350kV



























Rotors



TT2389 - T8i Rotor



Bearings



TT2392 - T8i Bearing Set - Front: 5 x 14 x 5mm / Rear: 5 x 11 x 5mm



Motor Parts



TT2390 - T8i Rebuild Kit: End Caps / Bearings / Solder Tabs / Isolator / Hardware

TT2391 - T8i End Caps / Hardware

TT2393 - T8i Sensor PCB

TT2394 - T8i Solder Tabs / Isolator
