RX4 ESC

Input Voltage: 2S - ALL

                         3S - ALL

                         4S - 2300kV

                         5S - 1800kV

                         6S - 1200kV

Weight: 197g / 6.95oz

Shaft Dimensions: 3.2mm (1/8") x 15.3mm

Motor Diameter: 35.8mm / 1.41"

Motor Length: 52.5mm / 2.10"

Bearing Dimensions: Front: 5 x 14 x 5mm / Rear: 5 x 11 x 5mm

Rotor Size: 18.5mm

Rebuildable: Yes





4 Pole 12 Slot Hi-torque Motor Design

CNC Machined 6061-T6 Billet Aluminum Heatsink Can

Crawler and Trail Rig Specific Design

Neodymium Sintered Magnets

Rebuildable Design

High Purity Copper Windings Maximizes Efficiency

Precision Engineered for Maximum Energy Conversion

Dual-Plug Sensor Wire Harness for use with all sensored and sensorless systems

High RPM ABEC5 Oversized Bearings





MOTOR ONLY



TT2600 - ROC 412 3100kV

TT2601 - ROC 412 2300kV

TT2602 - ROC 412 1800kV

TT2603 - ROC 412 1200kV





Rotors



TT2615 - ROC412 Rotor



Bearings



TT2612 - ROC412 Bearing Set - Front: 5 x 14 x 5mm / Rear: 5 x 11 x 5mm



Motor Parts



TT2610 - ROC412 Rebuild Kit: End Caps / Bearings / Solder Tabs / Isolator / Hardware

TT2611 - ROC412 End Caps / Hardware

TT2613 - ROC412 Sensor PCB

TT2614 - ROC412 Solder Tabs / Isolator
